Aviation & Hydraulic Test Equipment

Description

HYDRAULIC TEST EQUIPMENT MANUFACTURER- ONLINE ONLY AUCTION – OWNER RETIRING

AMERICAN LAB & SYSTEMS

181 S GEMINI AVE
BREA, CALIFORNIA 92821

PREVIEW: MONDAY, JULY 26TH FROM 9AM – 4PM, OR BY APPOINTMENT

BIDDING BEGINS JULY 20TH

LOT ONE ENDS JULY 27TH @ 11:00AM PDT WITH A 30 SECOND STAGGER BETWEEN LOTS

REMOVAL JULY 28-JULY 30, FROM 8AM-4PM- REMOVAL OF ASSETS NEEDING CRATING AND SHIPPING WILL BE BY APPOINTMENT THE FOLLOWING WEEK.

AFTER 44 YEARS IN BUSINESS, THE OWNER OF AMERICAN LAB & SYSTEMS, HAS DECIDED TO RETIRE. WE HAVE BEEN ENGAGED TO AUCTION ALL REMAINING ASSETS. ALS SPECIALIZED IN THE MANUFACTURE OF HYDRAULIC TEST STANDS, MULES, AND OTHER HYDRAULIC EQUIPMENT USED IN TESTING AIRCRAFT HYDRAULIC COMPONENTS. FOLLOWING IS A PARTIAL LISTING OF ASSETS TO BE SOLD:

HYDRAULIC UNITS

F-18 HORNET ELECTRO HYDRAULIC TEST STAND, HR TEXTRON, MDL HP-250, 65 GPM., 6,000 PSI, RATED FOR F-18 C, D, E, F, PRIMARY AND SECONDARY ACTUATORS, NOSE GEAR FLAPS, (1) FREE STANDING COMPUTER SYSTEM, HR TEXTRON TEST CONSOLE, (1) ZEMARC CORP. POWER UNIT, 0-30,000 LBS. TENSION OR COMPRESSION, 44" MAX LENGTH, 12" MAX STROKE, 250 HP, 1800 RPM, PARKER AXIAL PISTON PUMP, 250 GAL. RESERVOIR, OIL TO WATER HEAT EXCHANGER, 2.5 GAL. ACCUMULATOR, 3 MICRON HI-PRESSURE FILTRATION, 10 MICRON PARK LOW PRESSURE FILTRATION

PORTABLE HYDRAULIC MULE, HYDRAULIC INTERNATIONAL, DEUTZ DIESEL, 549 HRS., SKYDROL OIL, 36 L RESERVOIR, DUAL SYSTEM, 25 GPM PER SYSTEM @ 3KPSI/ 50 GPM, MISSING HYD. PUMPS, TUBES NOT CONNECTED, NO BATTERY, MISSING OIL TEMP & HYD. OIL GAUGES, NO THROTTLE, (#9)

PORTABLE HYDRAULIC TEST STAND, TELEDYNE, SER# 53970-3, 60 HP., 491 HRS., RED OIL, 230/460V, 3 PHASE, 1775 RPM, DENISON P1V07 PUMP, 30 GPM, 48 GAL. RESERVOIR, (#13)

PORTABLE HYDRAULIC TEST STAND, GREER HYDRAULIC INC., MDL HPE 45-2034, SER# T66182-48, 40 HP., SKYDROL OIL, 220/440V, 3 PHASE, 1750 RPM, DENISON PUMP, GRESON BOOST PUMP, NO RESERVOIR, (#14)

PORTABLE HYDRAULIC TEST STAND, ACL-FILCO CORP., TRUE DUAL SYSTEM, MDL MJ2A-1, DETROIT DIESEL, 1811 HRS., RED OIL, (2) PUMPS 226.26.00.01, 44 GAL. CYLINDER RESERVOIR, DAMAGED DOORS, DAMAGED TIRES, (#11)

HYDRAULIC TEST STAND, SKYDROL OIL, RECTANGULAR RESERVOIR 9H X 13.5W X 18 3/4L, 9 GAL., DIAPHRAGM PUMP, (#18)

HYDRAULIC TEST STAND, PUMP MDL PA-072, RED OIL, 18H X 20W X 17L RESERVOIR, 26 GAL, (#19)

STATIONARY TEST STAND, AMERICAN LAB & SYSTEMS, MISSING VALVES, MISSING DIAPHRAGM PUMP, (#21)

STATIONARY TEST STAND, A.C.L. TECHNOLOGIES, MDL 9770-0627, SER# 03663-002, 21 GAL. RESERVOIR, SKYDROL OIL, ACCUMULATOR, DIAPHRAGM PUMP MDL 10-50ERW040, 220V, MISSING FLOW METER, ELECTRICAL PARTS, HYDRAULIC PARTS, USED ON AIRCRAFT BRAKE, (#22)

TEST STAND, TESTEK INC., SER# 12010101, CARBON SEAL TESTER, MISSING PARTS, (#27)

TEST STAND, TESTEK INC., SER# 500470013, MDL A/E34T-3, TEST SET PNEUMATIC AIRCRAFT ENGINE COMPONENTS, (#28)

PORTABLE HYDRAULIC MULE, AMERICAN LAB & SYSTEMS, MDL HPPE303KS460, SER# 1247, SKYDROL OIL, 60 HP., 230/460V, 1760 RPM., OIL GEAR PVWH34L PUMP, 4844 HRS, PACO BOOST PUMP, 30 GPM, 49 GAL. RESERVOIR, MISSING HEAT EXCHANGER, (#2)

PORTABLE HYDRAULIC MULE, AMERICAN LAB & SYSTEMS, MDL HPPE303KS460, SER# 1245, SKYDROL OIL, 60 HP., 230/460V, 1760 RPM., OIL GEAR PVWH34L PUMP, BOOST PUMP, 30 GPM, 49 GAL. RESERVOIR, NO HOUR METER, MISSING AIR BLEED TUBE, GAUGE SHUT OFF VALVE, (#3)

PORTABLE HYDRAULIC MULE, AMERICAN LAB & SYSTEMS, MDL HPPE303KS460, SER# 1244, SKYDROL OIL, 230/460V, 60 HP., 1760 RPM., 3 PHASE, OIL GEAR OVWH34 PUMP, 8310 HRS., PACO BOOST PUMP, 30 GPM., 49 GAL. RESERVOIR, MISSING BOOST PUMP MOTOR, RETURN TEMP AND SYSTEM PRESSURE GAUGE, AIR BLEED & VALVE MISSING, (#4)

PORTABLE HYDRAULIC MULE, ACL TECHNOLOGIES, SKYDROL OIL, 60 HP., 230/460V, 1775 RPM, DENISON P7AV PUMP, 3487 HRS., 30 GPM, DENISON BOOST PUMP, 3H X 22W X 34.5L RESERVOIR, (#5)

PORTABLE HYDRAULIC MULE, ELECTRIC, MDL HPU303KS4, SER# 075, SKYDROL OIL, DENISON P1V07 PUMP, 30 GPM., ELECTRIC BOOST PUMP MOTOR, MISSING BOOST PUMP, (#6)

PORTABLE HYDRAULIC MULE, AMERICAN LAB & SYSTEMS, SKYDROL OIL, 60 HP., 230/460V, 3 PHASE, 1775 RPM, DENISON P1V07 PUMP, TUTHILL BOOST PUMP, ELECTRIC BOOST PUMP MOTOR, (#7)

PORTABLE HYDRAULIC MULE, SPRAGUE ENGINEERING, MDL PH30E, SKYDROL OIL, 60 HP., 230/440V, 1800 RPM, DENISON P1V07 PUMP, 30 GPM, TUTHILL BOOST PUMP, 136 GAL. RESERVOIR, (#8)

HYDRAULIC MULE, MDL T45 PHSC-9-3K-54, SER# 1328-009, 15 HP., SKYDROL OIL, 208-220/440V, 3 PHASE, DENISON P1V-05 PUMP, (#16)

PORTABLE HYDRAULIC MULE, AMERICAN LAB & SYSTEMS, MDL HPPE303KS460, SER# 1243, SKYDROL OIL, 60 HP., 230/460V, 1760 RPM., OIL GEAR PVWH34L PUMP, 1895 HRS, PACO BOOST PUMP, 30 GPM, 49 GAL. RESERVOIR, (#1)

ELECTRIC PORTABLE MULE, AMERICAN LAB & SYSTEMS, MDL ATA5-9-3K-54, SKYDROL OIL, 230/460V, DENISON PV05-006 PUMP, 1725 RPM, 0 HRS., 9 GPM, ELECTRIC BOOST PUMP, MISSING GAUGES, TOP COVER, RESERVOIR LID, (#36)

ELECTRIC TEST STAND, TESTEK INC., TAIL PLANE ACTUATOR HYDRAULIC CONSOLE, SER# 1663, CLOW CC-2X1 PUMP, 3718 HRS., 86 GAL. RESERVOIR, 75 GPM, (#37)



HYDRAULIC PUMPS, VALVES & COMPONENTS

MORE THAN 100 HYDRAULIC PUMPS, INCLUDING (47) DENISON 700-SERIES, (18) DENISON 22-SERIES, (6) DENISON 500 SERIES, (12) DENISON 600 SERIES, REX ROTH PUMPS, CI PUMPS & MANY MORE; DENISON 22 PUMP/MOTOR ASSEMBLY; DENISON P1V07 PUMP/MOTOR ASSEMBLY; HYDRAULIC PUMP REPAIR STATION, TWO POSITIONS, WITH HOIST & BEAM; LARGE ASSORTMENT OF PUMP PARTS, SKYDROL & RED OIL 0-RINGS

HYDRAULIC UNIT, HYDRAULIC INTERNATIONAL, DUAL SYSTEM, ELECTRIC, (2) 75 HP MOTORS, 230/460V, 1775 RPM, (2) DENISON PUMPS, RED OIL, PGT & T6C, SYSTEM #1 1937 HRS., SYSTEM #2 2064 HRS., DAMAGED TOP AND DOORS, (2) T6C BOOST PUMPS, 48 L. RESERVOIR, (#10)

ELECTRIC HYDRAULIC POWER UNIT, MISSING INFO TAG, RED OIL, 30 HP, 440 VOLT, 1750 RPM., DENISON P1V07 PUMP, MISSING GAUGE, AIR BLEED, HOSES, RESERVOIR, (#12)

PORTABLE HYDRAULIC UNIT, ELECTRIC, 60 HP., SKYDROL OIL, 220/440V, 3 PHASE, DENISON P1V07 PUMP, TUTHILL BOOST PUMP, NO HOUR METER OR RESERVOIR, (#15)
POWER UNIT, AMERICAN LAB & SYSTEMS, MDL HCTC-6, SER# 1429, 15 HP., 230/460V, 1750 RPM, DENSION PV0-5 PUMP, (#17)

HYDRAULIC POWER UNIT, AMERICAN LAB & SYSTEMS, SER# 1587, 100 HP., SKYDROL OIL, 220/440V, 127 HRS, 1180 RPM, DENISON PV09 PUMP, WATER COOLED HEAT EXCHANGER, MISSING PIPE ON HEAT EXCHANGER, 24H X 48W X 44L, 219 GAL., (#20)

TESTING PUMP, AMERICAN LAB AND SYSTEMS, RED OIL, DIAPHRAGM PUMP, (#23)

HYDRAULIC POWER UNIT, DENISON PA-072 PUMP, 20 HP., RED OIL, 230/460V, 1760 RPM, 10 GPM, 50 GAL. RESERVOIR, AIR COOLED, (#24)

ELECTRIC POWER UNIT, DENISON PUMP, 15 HP., 220/440V, 1200 RPM, 50 GAL. RESERVOIR, MISSING TUBES, (#25)

ELECTRIC POWER UNIT, DENISON PA-072 PUMP, 20 HP., 220/440V, 1770 RPM., 50 GAL. RESERVOIR, MISSING PARTS, (#26)

HYDRAULIC POWER CART, WESTERN SKYWAYS, SER# 5153, 7.5 HP, RED OIL, 208/230V, 1725 RPM., MISSING HYDRAULIC PUMP, 9 GAL. RESERVOIR, MISSING COVERS, (#29)

HYDRAULIC POWER UNIT, HYDRAULIC INTERNATIONAL, MDL H1P-100-22-35/HPU-1-5/HCC, SER# 0013, RED OIL, DUAL SYSTEM, (2) 100 HP MOTORS, (2) DENISON P6T & T6C-028 PUMPS, SYSTEM ONE 1048 HRS., SYSTEM TWO 564 HRS, (2) WATER HEAT EXCHANGERS, 77 GAL. RESERVOIR, 50 GPM BOOST PUMP, (#30)

HYDRAULIC POWER UNIT, HYDRAULICS INTERNATIONAL, MDL H1P-100-27-35/HPU-1-5/HCC, SER# 0008, RED OIL, DUAL SYSTEM, (2) 100 HP. MOTORS, 230/460V, 1780 RPM, (2) DENISON PUMP, SYSTEM 1 318 HRS, SYSTEM 2 218 HRS, 50 GPM BOOST PUMP, 77 GAL RESERVOIR, (2) WATER HEAT EXCHANGERS, (#31)

HYDRAULIC POWER UNIT, HYDRAULICS INTERNATIONAL, MDL H1P-100-27-35/HPU-1-5/HCC, SER# 0003, RED OIL, (2) DENISON PUMPS P6T & T6C-028, (2) 100 HP. MOTORS, 230/460V, SYSTEM ONE 931 HRS., SYSTEM TWO 414 HRS., 50 GPM BOOST PUMP, 77 GAL RESERVOIR, (2) WATER HEAT EXCHANGERS, (#32)

HYDRAULIC POWER UNIT, HYDRAULICS INTERNATIONAL, MDL H1P-100-22-35/HPU-1-5/HCC, SER# 0016, RED OIL, DUAL SYSTEM, (2) 100 HP MOTORS, 230/460V, 1780 RPM., (2) DENISON PUMPS P6T & T6C-025, 50GPM BOOST PUMP, 77 GAL. RESERVOIR, (2) WATER HEAT EXCHANGERS, MISSING PUSH BUTTONS, DIGITAL READ OUT, HOUR METER, (#33)

HYDRAULIC POWER UNIT, HYDRAULIC INTERNATIONAL, MDL H1P-100-22-35/HPU-1-5/HCC, SER# 0017, RED OIL, DUAL SYSTEM, (2) 100 HP MOTORS, (2) DENISON P6T & T6C-028 PUMPS, SYSTEM ONE 877 HRS., SYSTEM TWO 276 HRS, (2) WATER HEAT EXCHANGERS, 77 GAL. RESERVOIR, 50 GPM BOOST PUMP, DAMAGED FRONT ELECTRICAL PANEL, (#34)

HYDRAULIC POWER UNIT, HYDRAULIC INTERNATIONAL, MDL H1P-100-22-35/HPU-1-5/HCC, SER# 0022, RED OIL, DUAL SYSTEM, (2) 100 HP MOTORS, (2) DENISON P6T & T6C-028 PUMPS, SYSTEM ONE 877 HRS., SYSTEM TWO 276 HRS, (2) WATER HEAT EXCHANGERS, 77 GAL. RESERVOIR, 50 GPM BOOST PUMP, (#35)

PORTABLE POWER UNIT, AMERICAN LAB & SYSTEMS, 100 HP. MOTOR, SKYTROL OIL, 190/380V, 1475 RPM, DENISON P6T & T6C PUMPS, WATER HEAT EXCHANGER, 100 GAL. RESERVOIR, MISSING HYDRAULIC TUBES, (#38)

HYDRAULIC POWER CART, 10 HP. MOTOR, RED OIL, 230/460V, 1745 RPM., MISSING HYDRAULIC PUMP, 11 GAL. RESERVOIR, MISSING REGULATORS AND VALVES, (#39)

P.D.Q. LEAK TESTER, AMERICAN LAB & SYSTEMS, MDL A215-UN1V, SER# 1356 BROKEN DIGITAL SCREEN, NEEDS PLUMBING AND WIRING, (#40)

NEW SURPLUS COMPONENTS

(280) 2WAY BALL VALVE, JAMES BURY, ¼” FM NPT, NSN: 4820-01-247-3133, P/N: ¼-A-4436-TT, MOD – B, 10 PER BOX

4 WAY SOLENOID VALVE, RACINE, 4EA. -8 SAE PORTS, NSN: 4810-01-051-1611 VALVE ASSY., P/N: 916061

(33) 2 WAY BALL VALVE, D.M.I.C, 1 ½” SAE PORTS, P/N: 400, STEEL, MAX W/P: 6000PSI G

(33) HYD. SYSTEM RETURN FILTERS, PUROLATOR, 6X8 ELEMENTS ANG6236-3, P/N: 39797, ALUM., W/P: 200PSI AND 40GPM, ELEMENT: ANG236-3

(12) MANUAL ADJUSTABLE HYDRAULIC FLOW CONTROL VALVES, PARKER HAN/ COLOR FLOW, 1” FMNPT (2 PORT), STEEL, W/P: 3000PSI

(17) PILOT OPERATED HP RELIEF VALVE, VICKERS, 1 ¼” FMNPT, NSN: 4820-00-506-1289, P/N: CT10-10C-10, STEEL, W/P: 500/200 PSI G

(31) RETURN LINE FILTER, GRESEN THROW-AWAY, 10 MICRON, P/N: SERIES F-200, M/N: 1560-09, ALUM, W/P: 200 PSI, FILTER ELEMENT #: 3293-10


HYDRAULIC PUMPS, VALVES & COMPONENTS

MORE THAN 100 HYDRAULIC PUMPS, INCLUDING (47) DENISON 700-SERIES, (18) DENISON 22-SERIES, (6) DENISON 500 SERIES, (12) DENISON 600 SERIES, REX ROTH PUMPS, CI PUMPS & MANY MORE; DENISON 22 PUMP/MOTOR ASSEMBLY; DENISON P1V07 PUMP/MOTOR ASSEMBLY; HYDRAULIC PUMP REPAIR STATION, TWO POSITIONS, WITH HOIST & BEAM; LARGE ASSORTMENT OF PUMP PARTS, SKYDROL & RED OIL 0-RINGS

AEROQUIP QUICK-DISCONNECTS FOR CONNECTING TO AIRCRAFT

HUNDREDS OF HYDRAULIC VALVES, INCLUDING:
THOUSANDS OF HYDRAULIC FITTINGS, UP TO 1-1/2” STAINLESS

GAUGES

TUBE BENDING, FLARING & DEBURRING

TUBE BENDING TABLE WITH BENDER & DIES, 3/8” – 1”

TUBE BENDING TABLE W/BENDER & DIES, UP TO 1-1/2”
CRIMPER, GATES POWER CRIMP 707, INOP

(2) TUBE FLARING MACHINE, LEONARD TUBEMASTER MODEL 8, SN 3759

(2) FLARING/DEBURRING MACHINE, GATES


FABRICATION & WELDING EQUIPMENT

LAPPING MACHINE, LAPMASTER “36”, SN 35015, 208V
TOOLROOM LATHE, CRAFTSMAN, W/BENCH

IRONWORKER, PIRANHA P50, 50-TON

VERTICAL BAND SAW, DOALL 26”, VARIABLE SPEED, NO BLADE WELDER

BENDING BRAKE, ACRA 48” ON WHEELS

SHEET METAL SHEAR, BIRMINGHAM MODEL 11-5210, SN 88204, 1988

TIG WELDER, LINCOLN 275 PRECISION TIG

WELDER, MILLER MILLERMATIC 252

PLASMA CUTTER, THERMAL DYNAMICS CUTMASTER 51

HORIZONTAL MILL, BRIDGEPORT

DRILLING & MILLING MACHINE, DONCHO MODEL COMET-30, 12-SPEED

DRILL PRESS, DAKE MODEL SB-16, SN 60687, PEDESTAL-MOUNTED, 2005

HORIZONTAL BAND SAW, ELLIS MODEL 1600, SN 16111688, 7” ROUND CAP., 11” FLAT

HORIZONTAL BAND SAW, DAKE MODEL SE712, SN 572426, 7”X12”

MAG DRILL, BUX; MAG DRILL, MILWAUKEE 4221

PORTABLE “A”-FRAME HOIST, APPROX 10’ SPAN, W-1/2TN CHAIN HOIST

SANDBLAST CABINET, BENCH TOP

PORTABLE HEATERS, UNIVERSAL 350,000 BTU AND UNKNOWN BTU, ON PORTABLE STANDS

SEVERAL WELDING AND STEEL WORKTABLES


FORKLIFTS, TRUCKS, & MATERIAL HANDLING/STORAGE & SHOP EQUIPMENT

FORKLIFT, NISSAN MODEL J6F03A40V, SN UDF03-000624, 8,000 LB DOUBLE MAST, LP

FORKLIFT, SCHAEFF NAMCO MODEL E4000 C, W/CHARGER
FORKLIFT, ELECTRIC W/CHARGER

APPROX (15) AIR HOSE REELS, SPEEDAIRE & REELCRAFT

FLOOR SCRUBBER, CLARKE ENCORE” S” SERIES

DIGITAL PLATFORM SCALE, XL

PALLET RACKING; METAL STORAGE CABINETS

PARTS DRAWER CABINETS, STEEL SHELVES

ELECTRICAL
ELECTRICAL WIRE

(2) SIZE 6 MOTOR STARTERS

MANY SMALL MOTOR STARTERS

RELAYS; BREAKERS

LIQUID-TITE FITTINGS

TERMINALS

OFFICE & MISCELLANEOUS ITEMS

OFFICE DESKS, CONFERENCE TABLES, CHAIRS, COMPUTERS & PRINTERS; COMPUTER-AIDED ENGRAVING MACHINE, ROLAND PNC-2300A, SN ZM51476, WITH PC; FILE CABINETS, BLUEPRINT CABINETS & MORE.

TERMS OF SALE – AMERICAN LAB- BREA, CA

By registering for the above auction and submitting a bid, you agree to be bound by the following terms and conditions to Norman J. Gallivan, Inc., D/B/A Gallivan Auctioneers & Appraisers (“Auctioneer”) for this auction sale.

A 15% Buyer’s premium will apply to all onsite bids and an 18% Buyer’s Premium will apply to all Internet and Proxy Bids. Payment for all purchases must be made in full within 24 hours of the sale.

A 7% Indiana Sales Tax will be added to the purchase of new inventory and titled vehicles unless a copy of a resale certificate is provided at registration or checkout.

VISA, MasterCard, Discover, American Express, and Wire Transfers are accepted forms of payment. Cash will be accepted only at live, on-site sales. All purchases $10,000 and over must be made via wire transfer. All cash payments over $10,000.00 will be reported pursuant to government regulations.

Everything is sold “As Is/Where Is”. Although all descriptions of items to be sold are believed to be correct, the auctioneer and the owner make no warranties or guarantees of any kind whatsoever, other than the owner’s warranty of title, whether express or implied, as to the fitness, condition, authenticity of, or descriptions used in advertising. It is the sole responsibility of the bidder to verify fitness, condition, authenticity. and description of any item prior to bidding. Once the auctioneer or online platform says “Sold,” the purchaser is responsible for payment and safekeeping of the item(s) purchased. Removal of purchased items shall be at the expense, liability, and risk of the purchaser. Purchaser must provide a certificate of insurance if large equipment is to be used to remove purchased item(s).

If Purchaser does not remove their items within the designated removal period (hours/days) published for this auction, Purchaser will be deemed to have abandoned such item(s) and authorizes Auctioneer to dispose of the item(s) in a manner as Auctioneer sees fit in its sole discretion. The purchase price will not be returned to Purchaser, who shall also be liable to Auctioneer for the full cost of removal and/or disposal of abandoned items, plus reasonable attorney’s fees and court costs. If Purchaser fails to pay for item(s) bid on and abandoned, Purchaser authorizes Auctioneer to sell the item(s) in a subsequent auction. If, at a subsequent auction the item(s) sell for an amount less than Purchaser’s bid price, Purchaser agrees to be liable to Auctioneer for damages equal to the difference between Purchaser’s bid price and the subsequent auction purchase price, plus interest thereon from the date of the subsequent auction sale at the rate of eight percent (8%) per annum, reasonable attorney’s fees and court costs.

All bids and payments must be made in U.S. dollars (USD). No refunds for lost or stolen items will be made. Announcements made on the day of sale take precedence over any printed material. Advertised items may be subject to prior sale.

SEE MORE PHOTOS AT WWW.NJGALLIVAN.COM.

CALL OUR OFFICE WITH ANY QUESTIONS OR TO SCHEDULE AN INSPECTION.
AUCTIONEERS:
MATTHEW GALLIVAN AU10500124
NORMAN GALLIVAN AU09100059
NORMAN J. GALLIVAN, INC. AC32000003
